Description

• Tweeter: 1in
• Midrange: 4in
• Woofer: 7in
• Inputs: Analogue and AES3 digital inputs (no sample-rate conversion)
• Resolution: Maximum 24-bit / 192 kHz, depending on input signal (32, 44.1, 48, 96 & 192 kHz sample rates supported, analogue runs at 192 kHz)
• Max SPL: 112 dB @ 1 m anechoic / 118 dB half space
• Crossover frequency: 475 Hz (LF/MF) / 5250 Hz (MF/HF)
• Frequency response (- 6 dB): 37 Hz31 kHz
• Frequency response (+/- 3 dB): 44 Hz27 kHz
• Box principle: Front-loaded bass reflex
• Amplifiers: Pascal Class-D amplifiers: HF 150 W / MF 500 W / LF 500 W
• Dimensions: 390 mm, 355 mm, 240 mm (W x D x H)
• Weight: 15.1 kg
