Description

The DMX4-2.0 is a 4-channel dimmer/relay pack that provides DMX control for on/off or dimming to units that are not equipped with DMX on their own. It uses small LED fixtures to prevent ghosting and flickering. Its 4 sets of outlets can be set to any DMX address as well as independently set as a dimmer for relay. It is also equipped with 16 user-selectable chase patterns.
Features
4-channel dimmer/switch pack optimized for use with small LED fixture
Each channel can be set to any DMX address which makes it extremely easy to program
Each channel can be individually set as a dimmer or a switch which offers great flexibility
4 duplex outlets allow up to 8 devices to be controlled simultaneously
Separate LED indicators clearly show the status of each channel
Easy-access to built-in automated programs generate a synchronized show
Automated programs have adjustable speeds and dimmer levels which offer great control without DMX
DMX channels: 1, 2 or 4
Specifications
Power output: 5A per channel, 15A max
Input voltage equals output voltage
AC power: Autoswitching 100-240VAC 50/60Hz
Weight: 5lbs (2.2kg)
Size: 8.3 x 7.7 x 2.8in (210 x 194 x 70mm)
